Specyfikacja techniczna
Illumination System |
|
Slit width |
0-10mm, adjustable |
Slit length |
0.2, 1, 3, 6, 10 mm |
Diaphragm sizes |
0.2, 1, 3, 6, 10 mm |
Rotation |
0 - 180° |
Slit tilt |
Up to 20° |
Light source (bulb) |
12V 50W halogen lamp |
Filters |
Cobalt blue, heat absorption, 50% neutral density, light blue, open |
Microscope |
|
Type of microscope |
Binocular, Galilean-type |
Objectives |
0.4x, 0.67x, 1.7x, 2.67x |
Eyepieces |
15x |
Total Magnification |
6x, 10x, 16x, 25.6x, 40x |
Field of view |
6-37mm |
Method of changing magnification |
5– step drum rotation |
Binocular angle |
14.2° |
Pupillary Distance |
50-80 mm |
Diopter adjustment range |
-7 to +7 D |
Range of Movement |
|
Slide shift |
100 mm |
Depth shift |
80 mm |
Height shift |
29 mm |
Fine adjustment by joystick |
±10 mm |
Chin-rest height adjustment |
80 mm |
Unit Dimension |
|
Base |
24 x 15 cm |
Height |
68.5 cm |
Weight |
22kg |
Power Source |
100, 115, 220, 240 V |
